Automatic hydraulic brick mach...
■ Specifications
JYM 1280 block making machine features:
1.Up stroke model is a innovation, which increases the working pressure hugely.
The blocks made by Bona Hydraulic automatic block making machine features high density and intensity.
2.Bona fly ash concrete block making machine adopts Germany Technology servo motor,
which maintains precise positioning. The precision of material distribution is touching micrometer level.
3.Bona hydraulic automatic block making machine consumes sand,fly ash,coal gangue,
calcium carbide sludge, stone powder, Nickel-Iron slag,and other Industrial waste materials
containing Fe2O3 and SiO2 ect. The production cost is very low.
■ Technical Data
| Item | Name of parameters | specifications |
|
|
Fully automatic hydraulic brick machine | JYM-1280 |
| 1 | Max. Pressure(KN) | 12800 |
| 2 | Max.feeding height (mm) | ≤420 |
| 3 | Molding cycle(s) | 15～20 |
| 4 | Exhaust times | 3 |
| 5 | Size of end products | Standard brick：240×115×53 mm Hollow brick：240×115×90 mm Hollow block：390×190×190 mm |
| 6 | Pieces of each molding | 38～40 s |
| 7 | Row of mold | 2 |
| 8 | Productivity of standard brick (ten thousands) | ≥6000 |
| 9 | Rate of finished products (%) | 100 |
| 10 | Time for mold replacement(hour) | 1 |
| 11 | Overall power (kW) | 107.6 |
| 12 | Driving power (kW) | 90 |
| 13 | Overall dimension(length×width×height) | 7800×3290×4630 mm |
| 14 | Overall weight(Ton) | 55 |
